Skyrc Q200 Instruction Manual page 21

NiMH Auto CHARGE
CURRENT 1.3A
NiMH 1.3A 5.42V
AUT 002:22 00106
NiMH/NiCd Discharge Mode:
NiMH DISCHARGE
1.3A CUT:9.6V
NiMH 1.3A 10.42V
AUT 002:22 00106
Q200
NiMH/NiCd Battery Program
After selecting the correct battery type, use the INC or DEC
button to change the charge mode to the "Auto CHARGE"
setting.
Press the START button and the amp rate value will begin
flashing. Use the INC or DEC button to adjust the value to the
desired rate. Follow the instructions provided on your battery
when setting the upper charge amperage rate.
Press and hold the START button for 3 seconds to start charging.
Once charging has commenced, the charger will display the
following real-time information: battery type, charging current,
battery voltage, charging time and charged capacity.
Once the battery is fully charged, the screen will read "END:
FINISHED" and the charger will emit a ringing sound. You can
press the STOP button at any time during the charging process
to stop charging.
After selecting the correct battery type, use the INC or DEC
button to select the "DISCHARGE" mode. Press the START
button and the amp rate value will begin flashing. Use the INC
or DEC buttons to adjust the value to the desired discharge rate.
Press the START button again and the voltage cut-off will begin
to flash. Use the INC or DEC button to adjust the value to the
desired rate.
Follow the instructions provided on your battery when setting the
voltage cut-off. The Q200 will stop discharging when the battery
has reached the preset voltage cut-off.
Press and hold the START button for 3 seconds to start discharging.
Once discharging has commenced, the charger will display the
following real-time information: battery type, discharging current,
battery voltage, discharging time and discharged capacity.
19 ·
