UNIVIEW NVR201-04E User Manual page 80

External Interface
Network Interface
PoE Interface
USB Interface
Network
Incoming bandwidth
Outgoing bandwidth
Decoding
Live view/Playback
Capability
General
Power Supply
Consumption
PoE
Working Environment
Weight
Dimensions (W×D×H)
Table 5-3 NVR201-04L/08L
Video
IP Video Input
VGA Output
HDMI Output
Sync Playback
Audio
Output
NVR201-04EP
1 RJ45 10M/100M/1000M adaptive Ethernet interface
4 RJ45 10M/100M PoE+ interface
(802.3at)
1 USB2.0 interface, 1 USB3.0 interface
32 Mbps
96 Mbps
6MP@25, 4MP@30, 3MP@30, 1080P@30, 720P@30
18-ch@D1, 9-ch@720P, 4-ch@1080P
48 VDC, 1.8 A
≤8 W (without disk)
Max 30 W for single port
Max 64 W in total (8 W for each)
-10 °C to 55 °C(10 °F to 131 °F)
10% to 90% RH
<1.5 Kg (3.3 lb)(without disk)
<2.1 Kg (4.6 lb)(fully loaded with disks)
360.0 mm×254.3 mm×43.6 mm (14.17"×10.01"×1.72")
NVR201-04L
4-ch
1-ch
1-ch
4-ch
1-ch, RCA
74
NVR201-08EP
8 RJ45 10M/100M PoE+ interface
(802.3at)
64 Mbps
52 VDC, 1.8 A
NVR201-08L
8-ch
8-ch
