- Page 1 Network Video Recorders Quick Guide V1.04...
- Page 2 Indicators Status Description PWR(Power) Steady on Connected to power. Steady on Normal. RUN(Operation) Blinking Starting up. Steady on Activated for remote control. Blinking Authenticating device code. ALM(Alarm) Steady on Device alarm occurred. NET(Network) Steady on Connected to network. GUARD(Arming) Steady on Arming is enabled.
- Page 3 Interface Description Interface Description AC power Power on/off Audio in HDMI 1 output VGA output HDMI 2 output RS232 RS485 12V DC output Figure 2-2 Model 2 Interface Description Interface Description Grounding Audio in/out VGA output PoE ports HDMI output Network DC power Disk Installation...
- Page 4 Figure 3-1 Rear Panel Figure 3-2 Side Panel 2. Insert the screws into the disk and tighten the screws halfway. Screws 3. Slide the disk into place from A to B, and fix the screws to secure the hard disk. 4.
- Page 5 3.3.2 Install Disks Model A 1. Loosen the screws of the mounting plate on the side panels. 2. For the 4-HDD device, turn the upper mounting plate in the shown direction, and remove the plate. For the 8 or 9-HDD device, repeat the steps to remove the upper mounting plate, and then remove the lower mounting plate.
- Page 6 4. Put the mounting plate back in place. Connect the power cables and data cables as shown in the figure. Repeat the steps to connect all the disks. NOTE! Please use the shorest hard disk data cable to connect the hard disk in slot 9 for easy installation. 5.
- Page 7 2. Fasten the brackets installed with hard disks to the device. 3. Connect the power cables and data cables. Power cable Data cable 8 or 16 HDD Installation 1. Fix the mounting brackets to the disk with screws. With the disk interface side down, install the R (for right) and L (for left) bracket according to the figure below.
- Page 8 Slot 1 Slot 2 4. Install the front panel. Startup and Shutdown Make sure the cables are connected correctly and the device is grounded properly. Use a power supply that meets requirements. Startup Connect the device to power to start the device. If the device has a power switch on the rear panel, you need to turn on the power switch to start the device.
- Page 9 NOTE! After the device is added, if wrong username or password message shows in the preview window, click in the window toolbar and enter the correct username and password. 5.1.2 Custom Add 1. Right click in the preview page, click Menu > Camera > Camera. 2.
- Page 10 ©2021-2024 Zhejiang Uniview Technologies Co., Ltd. All rights reserved. No part of this manual may be copied, reproduced, translated or distributed in any form or by any means without prior consent in writing from Zhejiang Uniview Technologies Co., Ltd (referred to as Uniview or us hereafter).
- Page 11 To the extent allowed by applicable law, in no event shall Uniview’s total liability to you for all damages for the product described in this manual (other than as may be required by applicable law in cases involving personal injury) exceed the amount of money that you have paid for the product.
- Page 12 To the extent not prohibited by applicable law, in no event will Uniview and its employees, licensors, subsidiary, affiliates be liable for results arising out of using or inability to use the product or service, including, not limited to, loss of profits and any other commercial damages or losses, loss of data, procurement of substitute goods or services;...
- Page 13 Verify that the device is properly installed before connecting it to power. Do not remove the seal from the device body without consulting Uniview first. Do not attempt to service the product yourself. Contact a trained professional for maintenance.
- Page 14 (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Visit http://en.uniview.com/Support/Download_Center/Product_Installation/Declaration/ for SDoC. Caution: The user is cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
