Settings
The Settings menu allows to configure main settings of the device.
PARAMETER SETTING
12 case-sensitive alphanumeric
Name
characters
Quick
Bal/Mix ; Clone ; Off
Menu
Contrast
Low timeout
Display
Off timeout
Full
LED
Alarm
OFF
Infrared
By this menu, MPR50-IEM can be connected to IRDA for setup or firmware upgrades.
When the Infrared interface is active, the following screen is displayed.
NOTE: while in this menu display is not automatically turned off.
14
MEANING
The name menu allows to change the name of the
receiver. This is the name displayed in the top of
the Status display and it is the name sent to the
transmitter with the sync function (for the
transmitter with this advanced capability).
Use the UP/DOWN buttons to change the selected
character and push SEL button to switch to the
next character.
The quick menu is displayed pushing UP or DOWN
buttons when the receiver is on the
Set to Bal/Mix to enter quickly to the Balance/Mix
mode menu (according to the Out mode
configured).
Set to "Clone" to enter quickly to the Load clone
menu
Set to "Off" for disable this function (if is set "Off"
and UP or DOWN buttons are pushed, nothing
happens).
0÷5 Change contrast display from 0 (min) to 5 (max).
Low timeout sets the timeout from 5 to 60 seconds
5÷60 (steps 5)
(5sec steps) to decrease the brightness display.
Off timeout sets the timeout from 10 to 120
10÷120 (steps 10)
seconds in 10 sec. steps to turn off the display.
or OFF
With OFF setting the display never turns off.
3 LED setting are available:
Full: LED indicators works normally;
Alarm: LED indicators lights up only when an alarm
happened;
OFF: LED indicators remain off.
MPR50-IEM User Manual
Rev. 01
Status display.
