Digital output magnetometers: supported commands

Table 10. Digital output magnetometers: supported commands list

devices/demonstration boards including a digital output magnetometer.
Command
*setdbXXXVY Selects firmware according to the adapter connected
*start
*debug Returns the output data in readable text format
*stop
*Zon
*Zoff
*dev
*ver
*mrAA
*mwAADD
*single It gets a single X, Y, and Z data acquisition
*list
*listdev
*echoon
*echooff
(1) Magnetometer "Reset mode" enable
*mfiforst
(1)
*mfifomde
(1) Magnetometer "FIFO Stream" enable
*mfifostr
(1) Magnetometer "Stream-to-FIFO" enable
*mfifostf
(1) Magnetometer "Bypass-to-FIFO" enable
*mfifobtf
(1) Magnetometer "Bypass-to-Stream" enable
*mfifobts
(1) Magnetometer "Dynamic Stream" enable
*mfifodstr
1. Available only for devices with embedded FIFO.
UM0979 - Rev 6
Table 10. Digital output magnetometers: supported commands list
Description
Starts continuous data acquisition
Stops data acquisition
Forces 3-state
Exits from 3-state
Device name
Firmware version
Magnetometer register read
Magnetometer register write
Prints the list of MKIs supported
Prints the list of devices supported
Activates the write verbose mode
Deactivates the write verbose mode
Magnetometer "FIFO mode" enable
below lists the commands supported by the
Returned value
(see Table 4. Returned values for *start
(see Table 5. Returned values for *debug
e.g.: LIS3DH
e.g.: V1.0
e.g.: MRAAhDDh
(see Table 5. Returned values for *debug
e.g.: MKI105V1
e.g.: LIS3DH
e.g.: MRAAhDDh
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
UM0979
Supported commands
command)
command)
command)
page 27/39
