Command
*gfifostr
*gfifostf Gyroscope "Stream-to-FIFO" enable
*gfifobtf Gyroscope "Bypass-to-FIFO" enable
*gfifobts Gyroscope "Bypass-to-Stream" enable
*gfifodstr Gyroscope "Dynamic Stream" enable
*mfiforst Magnetometer "Reset mode" enable
*mfifomde
*mfifostr Magnetometer "FIFO Stream" enable
*mfifostf Magnetometer "Stream-to-FIFO" enable
*mfifobtf Magnetometer "Bypass-to-FIFO" enable
*mfifobts Magnetometer "Bypass-to-Stream" enable
*mfifodstr Magnetometer "Dynamic Stream" enable
*pfiforst Pressure sensor "Reset mode" enable
*pfifomde Pressure sensor "FIFO mode" enable
*pfifostr Pressure sensor "FIFO Stream" enable
*pfifostf Pressure sensor "Stream-to-FIFO" enable
*pfifobtf Pressure sensor "Bypass-to-FIFO" enable
*pfifobts Pressure sensor "Bypass-to-Stream" enable
*pfifodstr Pressure sensor "Dynamic Stream" enable
*PDON
*PDOFF
*STON
*STOFF
*HPON
*HPOFF
*FSON
*FSOFF
Note: IR: interrupt byte; FC: FIFO control register; FS: FIFO source register.
Set demonstration board
The command *setdbxxxvy selects the part of the firmware able to handle the adapter board sensor connected to
the board. e.g., in order to select the firmware for the LIS3DH the command must be: *setdb105V1. The D6 LED
(green) is automatically switched on.
Start command
The *start command initiates the continuous data acquisition. When this command is sent to the device, it returns
a string of bytes (plus carriage return and line feed) similar to "st OUT1 OUT2 OUT3 IR BT".
The first two bytes are always the ASCII char "s" and "t" which correspond to the hexadecimal values {73h 74h}.
OUT1, OUT2, and OUT3 are the bytes that contain the values measured at device outputs; if the output data is
represented on more than 8 bits, OUT1, OUT2, and OUT3 are split into two bytes: high byte (e.g.: "XH") and low
byte (e.g.: "XL").
IR contains the interrupt bytes and BT contains the bytes that describe the state of the buttons integrated on the
board.
UM0979 - Rev 6
Description
Gyroscope "FIFO Stream" enable
Magnetometer "FIFO mode" enable
Sets power-down pin
Clears power-down pin
Sets self-test pin
Clears self-test pin
Sets high-pass filter pin
Clears high-pass filter pin
Sets full-scale pin
Clears full-scale pin
UM0979
Supported commands
Returned value
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
st 0 0 0 0 0 0 IR FC FS
