Configuring 4000 Appliances
https://supportcenter.checkpoint.com/supportcenter/portal?eventSubmit_doSwichtab=Documen
tation&tab=Documentation.
Note: From R77, the Installation and Upgrade Guides are released only for major versions and
by Gaia or non-Gaia platforms. For example, for the Gaia platform R77.10 version, see the R77
Versions Installation and Upgrade Guide for Gaia Platforms.

Creating the Network Object

Configure the 4000 Appliances as a gateway object in the Security Management Server
database.
To create the network object in SmartDashboard:
1. Launch SmartDashboard.
2. Configure a new gateway object for the appliance.
3. Enter the IP address for the appliance.
4. For a centrally managed installation, establish Secure Internal Communication (SIC) using
the activation key entered in the First Time Configuration Wizard.
5. Configure the topology.
6. Install the security policy.

Advanced Configuration

Advanced configuration on Gaia
Advanced configuration on Gaia can be done from the WebUI or the CLI.
Advanced configuration on SecurePlatform
Advanced configuration on SecurePlatform can be done with the sysconfig menu from the
CLI.
Note - The sysconfig menu is only available after running the First Time
Configuration Wizard in the WebUI.

Connecting to the CLI

After you complete the First Time Configuration Wizard, you can connect to the CLI (command
line interface) of a 4000 Appliances using:
• The provided serial console cable (DTE to DTE)
• Terminal emulation software such as HyperTerminal and PuTTY (from Windows), or
Minicom (from Unix/Linux systems).
• Connection parameters for the appliance are: 9600 bps, no parity, 1 stop bit (8N1).
• Set the Flow Control to None.
• An SSH connection to the management interface (if SSHD is configured).
26 | Check Point 4000 Appliances Getting Started Guide
