4000 Appliances Hardware

Check Point 4800 Front Panel

Item Description
1 Expansion line card slot
2 LOM Port
3 Built in Ethernet ports (ETH1 - ETH7)
4 Management configuration port - Ethernet connection to a remote management
workstation
5 USB ports
6 Console port - A serial connection to the appliance using a terminal emulation program
such as HyperTerminal or PuTTY
7 Power indicator LED
8 LCD display screen
9 Keypad
Lights Out Management
The Check Point Lights Out Management (LOM) card lets you use a dedicated management
channel to remotely control Check Point appliances. Lights Out Management can also work
when the appliance is turned off or not responding.
For more about using Lights Out Management, see the 4800 and 12000 Appliances Lights Out
Management Administration Guide http://supportcenter.checkpoint.com.

Using the LCD Panel

The appliance has an LCD panel that you can use to do these basic management operations:
