Auxiliary Inputs

Pro Tools Auxiliary Inputs are used as buss and
effects returns for both internally-bussed signals
and external sources. The methods for assigning
inputs and outputs on Control 24 are essentially
the same as for audio tracks.
You can use an Auxiliary Input to create a sub-
mix of any combination of channels. By routing
channels to the Auxiliary Input instead of to the
main mix outputs of your session, you can:
• Apply real-time plug-ins.
• Apply an external processor to the submix.
• Consolidate control of multiple channels un-
der a single fader.
See the Pro Tools Reference Guide for more about
auxiliary tracks.
To route an Auxiliary Input:
Make sure you are in Home or Sends mode.
1
Press ASSIGN. The ASSIGN and ESC/CANCEL
2
buttons will both flash.
Press INPUT. This button will light.
3
The scribble strip for each track will display
4
default (or previously-assigned) input routing
configurations.
Adjust the data encoder knob to scroll
5
through the list of available inputs on each track
you want to configure.
When the abbreviated name of the input you
6
want appears in the scribble strip, press the
flashing button directly below the data encoder
knob to confirm your decision.
104 Control 24 Reference Guide
Adjust the data encoder knobs on any other
7
tracks for which you would like to make input
assignments. Press the flashing buttons directly
below the data encoder knobs to confirm any
other choices.
Press ASSIGN or ESC/CANCEL to leave Input
8
Assignment mode. The ASSIGN and ESC/CAN-
CEL buttons will stop flashing to indicate that
you have left the Assignment mode.
Your routing assignments will not be saved
if you press the ESC/CANCEL button with-
out first confirming your selections by press-
ing either the master ASSIGN button or the
flashing button directly below the data en-
coder knob on each selected track.
Routing assignments cannot be made while
the Pro Tools transport is engaged.

Master Faders

Master Faders are used to control levels and in-
sert processing for various types of mix and sub-
mix outputs.
You can use Master Faders freely to control sub-
mix levels, send level masters and main mix out-
put levels without consuming any of your sys-
tem's audio processing power.
Control 24 is uniquely handled to put master
faders at your fingertips. You can assign as many
Master Faders as you wish, and bring them up
on Control 24's faders with a single press on the
MASTER FADERS button.
See the Pro Tools Reference Guide for more about
master faders.
