Neuro Hub

The Source Audio Neuro Hub (sold separately) unites Source Audio pedals from the Soundblox 2 and
One Series families to create a single, stage-ready effects system. It features shared MIDI, passive
expression pedal input, Hot Hand connectivity, and USB, and can connect up to five Source Audio
pedals. The Neuro Hub features a powerful scene saving functionality, which allows you to create up
to 128 multi-pedal presets known as scenes, each recallable via MIDI program change messages.
Connect the Neuro Hub to your computer via USB for updates, saving and editing multi-pedal
presets, and more. To connect the Ventris to the Neuro hub, use a 3.5 mm TRRS cable and make a
connection between the Ventris's C
outputs. For more information, refer to the Neuro Hub documentation on the Source Audio website.

MIDI

Using the MIDI IN jack (5-pin DIN) or a USB connection, the Ventirs can be controlled by generic MIDI
Continuous Controller (CC) and Program Change (PC) messages. Many of the Ventris's parameters
(even those that are not assigned to a control knob) are directly accessible via MIDI continuous
controller messages.
MIDI Channel
By default, the Ventris responds to MIDI Channel 1. The Ventris ignores all MIDI messages sent to it
that are not on its channel. The input MIDI channel for the Ventris can be changed in the Hardware
Options menu of the Neuro Editors. Note that the MIDI Input Channel is a global setting that is NOT
saved per preset. Note that some manufacturers begin counting MIDI channels at zero (from 0 to
15), while the Source Audio Neuro Editors use the convention of counting from 1 to 16.
Selecting Presets via Program Change (PC) Messages
The 128 user presets on the Ventris can be recalled via program change messages. Presets 1 to 128
are mapped to MIDI Program Change messages 1 to 128.
It is possible to save presets with the Ventris bypassed. This means the preset can be recalled
without actually engaging the reverb effect. The reverb effect can then be engaged either by pressing
the O /O F
N FF OOTSWITCH
Many of the parameters in the Ventris can be controlled via MIDI. For more details, see
Implementation.
Controlling the Ventris with MIDI Continuous Controller (CC) Messages
The Ventris responds to MIDI Continuous Controller (CC) messages. Many Ventris parameters are
already mapped to particular CC numbers, but it is also possible to custom map CCs. To map MIDI CC
messages open the Neuro Desktop Editor, select Device in the top bar navigation, and select Edit
Device MIDI Map to open the MIDI Map tool. Simply select the dropdown menu next to your
preferred CC number, and choose a parameter. The table below is a guide to the default MIDI
mapping.
SA262
I
ONTROL NPUT
or by sending the proper MIDI Continuous Control message.
Ventris Dual Reverb Owner's Manual
jack and any of the Neuro Hub's multi-function
