Switch. Within each of the 128 Presets the adjustable settings include reverb engines, knob and
Neuro parameters, routing options, and external control options.
1. Select the preset you would like to edit by clicking the SELECT/(HOLD) SAVE Button until the
corresponding P
program change (PC) message.
2. Move the A/B Reverb Toggle Switch to position A and use the knobs or Neuro App/MIDI to set
up the sound to your liking. The P
edited.
3. Press and hold the SELECT/(HOLD) SAVE Button. Continue holding the SELECT/(HOLD) SAVE until
the P LED blinks fast, then slow, and eventually turns solid. This indicates that the preset
RESET
has been saved. To copy a preset from one location to another, see the
section below.
*Note: To save a preset to the position B on the A/B Reverb Toggle Switch, follow the same process,
but select toggle switch position B in step 2.
Editing and Saving a Dual Engine Preset to Reverb A+B
Within each of the 128 Presets available on the Ventris Dual Reverb it is possible to save an entirely
different collection of settings for both the A and B Reverbs. It is also possible to combine two
reverbs by selecting the A+B position on the A/B Reverb Toggle Switch.
It should be noted that there are two signal routing modes available when creating dual reverb
presets (A+B): Parallel Mode and Cascade (a.k.a. Series) Mode. The differences are as follows:
•
Parallel Mode: By default Reverb A+B runs in Parallel Mode. Parallel Mode routes Reverb A
and Reverb B side-by-side, then combines them for the final mono or stereo output signal. In
A+B/Parallel Mode the functions of the CONTROL 1, CONTROL 2, and MIX knobs change:
CONTROL 1 sets the wet level of Reverb A, CONTROL 2 sets the wet level of Reverb B, and
MIX sets the level of the dry signal. The figure below illustrates the Parallel/A+B signal path
and altered knob functions.
•
Cascade Mode: (a.k.a. "Series Mode"): Cascade Mode is the alternate dual reverb mode. It
routes Reverb A and B in series, Reverb A cascading into Reverb B. This Mode functions just
as if you were running one reverb pedal into another in a traditional pedalboard signal chain.
To enter Cascade Mode switch the A/B Reverb Toggle Switch to position A, hold down the
SA262
LED is lit. When using MIDI, select the preset with the corresponding MIDI
RESET
RESET
Dual Parallel Knob Controls (toggle = A+B)
Analog Dry Level
MIX
Reverb A Level
1
CONTROL 1
Reverb B Level
CONTROL 2
Ventris Dual Reverb Owner's Manual
LED will begin to blink, indicating that the preset is being
Analog Dry Path
Reverb
A
Reverb
B
Copying a Preset
1
