Please note that when the A/B Reverb Toggle Switch is set to the A+B position, the function of MIX
and CONTROL 1 & 2 change. In A+B mode the CONTROL 1 knob adjusts the wet level of reverb A,
CONTROL 2 adjusts the wet level of reverb B, and the MIX knobs adjusts the level of the dry signal.
Using the Mix Knob to Set Master Output Level
The overall output volume level is adjustable on the pedal hardware without needing to use Neuro
Editing Software or MIDI. Press and hold the CONTROL INPUT button and then turn the MIX knob to
set the master output level, which affects both the wet signal and the dry signal. A maximum of +6
dB of boost is possible. The following figure shows the range of output gains, in decibels (blue) and
linear (red). Note that when the output level is adjusted, it will be maintained while changing effect
engines using the effect dial. Loading a user preset will override the level set by the MIX knob.
Pre-Delay Knob
Sets the amount of time between the dry signal and the initial reverb reflections. As the PRE-DELAY
knob is turned clockwise the pre-delay time increases creating a sound similar to a natural echo or
"slapback" effect.
Treble Knob
Controls the amount of high frequency damping applied to the wet signal. Turn the knob clockwise
for a brighter reverb trail and counter-clockwise for a darker reverb.
Control 1 and Control 2
Because of the wide tonal possibilities of each reverb engine in the Ventris Dual Reverb, it was
necessary to arm the pedal with two "wildcard" knobs labeled CONTROL 1 and CONTROL 2. The
function of the CONTROL knobs varies depending on the active reverb engine. Details on the function
of each knob are available in the
alternate parameters to the CONTROL 1 & 2 knobs. CONTROL knob reassignments can be saved to
individual presets or to any of the engines on the EFFECT SELECTOR knob. Go to the
Editor section for details on assigning alternate CONTROL knob parameters.
Please note that when the A/B Reverb Toggle Switch is set to the A+B position, both Reverbs A and B
are running simultaneously and the function of the MIX and CONTROL 1 & 2 knobs change. When
running the reverbs in Parallel, CONTROL 1 sets the wet level of Reverb A, CONTROL 2 sets the wet
level of Reverb B, and MIX sets the level of the dry signal. When running the reverbs in Series (a.k.a.
"Cascade"), CONTROL 1 sets the wet/dry mix of Reverb A, CONTROL 2 sets the wet/dry mix of Reverb
B, and MIX sets the level of the dry signal. See the
complete instructions on dual reverb presets.
SA262
0 dB
1.0
-6 dB
0.5
-∞ dB +6 dB
0
Reverb Engines section
Editing and Saving Dual Engine Presets
Ventris Dual Reverb Owner's Manual
+3.5 dB
1.5
2.0
of this manual. It is also possible to assign
Neuro Sound
section for
