Source Audio Ventris Dual Reverb User Manual page 25

the Reverb not currently in use. For example, you can play through Reverb A, the press the OPTION
switch to summon and hold the trail of Reverb B – all the while maintaining the undisturbed
reflections of Reverb A (See the illustration below for additional clarity).
Option LED
The OPTION LED (located above the OPTION Footswitch) indicates the Pre-Delay time or LFO rate when
using the OPTION Footswitch as a Tap Tempo control. When the OPTION footswitch controls Tap
Tempo of Pre-Delay, the LED will blink in time. When Tap Tempo controls the rate of modulation
effects, the LED will employ a smooth pulsing illumination. The LED also illuminates solidly when the
HOLD or BUILD functions are engaged.
Control Input Button
This small button located at the top of the pedal is used when configuring external control. See the
External Control section for more details.
External Control LED
The small LED located to the left of the M
that external control mode (expression or MIDI) is active or that incoming data is being received via
MIDI or a Neuro connection. For more information, see the
Preset Select/(Hold) Save Button and LEDs
Press the SELECT button to scroll through and select saved user presets. The four P
the P B indicate which preset is active for presets 1 through 4. If a preset has been
RESET UTTON
modified, the corresponding P
– the associated preset LED will blink for a few seconds. When the LED stops blinking, the updated
preset will be saved to the current preset position.
Preset Extension Mode: Allows for easy access to an additional 4 presets for a total of 8 onboard
presets. To enable Preset Extension Mode, go to the Hardware Options sections of the Neuro Mobile
or Desktop Editor (see
patterns of the Preset Select LEDs indicate which Preset has been selected (see the figure below).
SA262
"Hold Other Engine" Function (Holding Reverb B)
K
IX NOB
LED will blink slowly. To save a preset, press and hold this button
RESET
Neuro Hardware Options) and select the appropriate option. The illumination
Ventris Dual Reverb Owner's Manual
is the C /ACTIVITY L
ONTROL
External Control
. When lit, it indicates
ED
section.
LED next to
RESET S
25
