Source Audio Ventris Dual Reverb User Manual page 37

With the Neuro Editor, it is also possible to assign a number of different control functions to an
external switch. Additional external switch options include A to B Reverb Toggling, A to A + B Reverb
Toggling, Tap Tempo, Hold (a.k.a. "Freeze"), and Build. Go to the
section for a full description of each External Switch Option.
External Switches (1/8" TRRS Connection)
The Source Audio Tap Tempo footswitch can also be connected to the CONTROL IN jack using a
3.5mm (1/8 inch) cable. If you wish to use this function, you must enable the function globally with
the Use Control Input for External Switch option in the
Desktop Editor. You also need to use the Control Input dropdown menu to select the function of the
Tap Tempo switch. Options include Preset Increment, Preset Decrement or Engine Tap Function (this
option mimics whichever option has been selected (per preset) in the Option Tap dropdown menu of
Option Footswitch Assignment
Source Audio Tap Tempo footswitches can be purchased directly from the
Online Store.
External Expression Control
A variety of the Ventris's effects parameters can be controlled with a passive expression pedal
connected to either the PEDAL IN or the CONTROL INPUT port. The expression pedal can be mapped
to simultaneously control any combination of up to three knobs or Neuro parameters. Mapping
parameters can be done either in the
by itself (see the Configuring Expression Pedal
to an expression pedal without the Neuro Desktop).
External Expression Controller (1/4" TRS Connection – PEDAL IN jack)
Passive expression pedals such as the Source Audio Dual Expression Pedal or Reflex Universal
Expression Pedal can be connected directly to the 1/4" P
the PEDAL IN switch (next to the PEDAL IN jack) is set to EXP when using this input for expression
control. Third-party expression pedals can be used as well, as long as they have a TRS (Tip Ring
Sleeve) plug with power on the ring, expression (the wiper of the potentiometer) on the tip, and
ground on the sleeve, as seen in the diagram below.
SA262
section of the Sound Editor).
External Control
section for instructions on mapping knob parameters
Gr ound Power
Ventris Dual Reverb Owner's Manual
Neuro Editor's Footswitch Options
Hardware Options section of the Neuro
Official Source Audio
section of the Neuro Desktop or with the pedal
I jack with a TRS cable. Make sure that
EDAL N
Expr ession
37
