Auto Routing and Default Modes
By default, the Ventris detects what has been plugged into its inputs and outputs and sets the routing
mode automatically. The table below summarizes each Auto Routing Mode and its corresponding
cable connections.
INPUT 1 INPUT 2
Connected
Connected Connected Connected
Connected
Connected Connected Connected
Yes Neuro
Please note that by default switching the A/B Reverb Toggle Switch to the A + B position will
simultaneously run Reverbs A and B in parallel and mix them together (in stereo) to the Outputs. It is
also possible to run the reverbs in series (Reverb A into Reverb B). To run the reverb engines in series,
first flip the toggle switch to either the A or B Reverb, then hold down the CONTROL INPUT button (at
the top of the pedal) and switch the toggle back to the A + B position – the reverbs now run in series.
Follow the same process to switch back to parallel processing
Warning: If you connect the Neuro App cable from your mobile device to INPUT 2, the Ventris will
detect it as an audio input and adopt one of the Stereo In Modes, which might create additional noise
and affect the stereo signal. This is especially true when the Neuro App cable is not connected to the
phone. You can override this action by going into the app and selecting the Mono In routing mode
that you want. If you want to connect a stereo input AND the Neuro App cable into INPUT 2, use a
TRS (Tip, Ring, Sleeve) stereo splitter and make sure that the Neuro signal is on the Ring and the
instrument signal is on the Tip (the Sleeve acts as the ground).
SA262
OUTPUT 1 OUTPUT 2
Connected
Connected Connected
Connected
Ventris Dual Reverb Owner's Manual
Resulting Auto Routing Mode
Mono in, Mono Out, Dual Parallel
Stereo in, Mono Out, Dual Parallel
Mono in, Stereo Out, Dual Parallel
Stereo in, Stereo Out, Dual Parallel
Unplug, manually set routing, or use a splitter.
