Overview - Source Audio Ventris Dual Reverb User Manual

Overview

Over 20 Diverse Reverb Engines – Choose from vintage Spring, Plate, and Hall sounds, natural Room
sounds, and unnatural Shimmer, Reverse, and Swell reverbs. 12 factory reverb engines are available
out of the box with additional engines available via the Neuro Mobile App or Desktop Editor.
Flexible Stereo Routing – Ventris is equally at home in a mono or stereo rig. Every reverb effect
engine works in True Stereo (stereo in > stereo out), Mono-to-Mono, Mono-to-Stereo, Mono-to-
Mono plus dry signal to Output 2, and more. It is also possible to create an external effects loop.
Dual Reverb Processing – Features two completely independent reverb processors – essentially
providing two high-powered reverb pedals in a single enclosure. Its dual reverb platform gives the
pedal massive processing power as well as some highly advanced features like unlimited Preset
Spillover and the ability to combine two reverb effects in either series or parallel.
Preset Spillover - Two individual signal processors make it possible to change from one preset to
another without abruptly cutting off the reverb trail of the original preset. Seamless and unlimited
"spillover" is an enormous advantage in live situations and there are no limitations to the duration of
the transition. Note: Spillover is unavailable when changing between two dual reverb presets (A+B on
the toggle switch).
Dual Reverb Presets (In Series or Parallel) - Select the A + B toggle switch position and create dual
reverb effects, allowing you to simultaneously engage two different reverb effects with a parallel,
cascaded, or left/right signal path.
Analog Dry Through – While engaged the incoming dry signal bypasses the effects processors
entirely (for most engines), thereby maintaining a 100% pure dry signal without D/A conversions.
Universal Bypass – Select between true bypass, buffered bypass, or soft bypass with reverb trails.
The Ventris features high-quality signal relays for true bypass and transparent buffers for analog
bypass.
Compact Design – The extruded anodized aluminum housing, with its slim profile and small footprint,
is built for the rigors of the road.
Presets – Save your favorite sounds with the touch of a button. Save up to 8 presets recallable with
the pedal's onboard controls, plus a total of 128 presets recallable with an external MIDI controller.
Deep Control Set – Beyond the six control knobs on the face of the Ventris are many additional,
editable parameters. The Neuro Mobile App and Neuro Desktop Editor provide access to a vast
collection of additional parameters for advanced users who want to create highly customized reverb
effects.
SA262 Ventris Dual Reverb Owner's Manual 3
