Source Audio Ventris Dual Reverb User Manual page 28

CONTROL INPUT button then switch the Toggle Switch back to A+B (To switch back to Parallel
Mode, repeat the process without holding down the CONTROL INPUT button). When
combining the reverbs in Cascade Mode, CONTROL 1 sets the wet/dry mix of Reverb A,
CONTROL 2 sets the wet/dry mix of Reverb B, and MIX sets the level of the dry signal. The
figure below illustrates the Cascade/A+B signal path and altered knob functions.
Dual Cascade Knob Controls (toggle = A+B)
1
Follow the instructions below to create dual reverb presets:
1. Select the preset you would like to edit by clicking the SELECT/(HOLD) SAVE Button until the
corresponding P
RESET
2. Select Reverb A with the A/B Reverb Toggle Switch and dial in your settings with the front panel
controls or Neuro Editor.
3. Flip the A/B Reverb Toggle Switch to Reverb B and dial in the settings for Reverb B. Please note
that it is possible to use different reverb engines in Reverbs A and B.
4. Flip the A/B Reverb Toggle Switch to A+B. By default the A+B reverb is routed in parallel, if you
wish to run your Reverbs in series (Note: Reverb A always cascades into Reverb B), flip back to
Reverb A, press and hold the CONTROL INPUT button at the top of the pedal, and switch the
toggle back to A+B. The A and B Reverbs will now run in series. To switch back to Parallel Mode,
repeat the process without holding down the CONTROL INPUT button.
5. In A+B Mode the functions of the CONTROL 1, CONTROL 2, and MIX knobs change. When
running the reverbs in Parallel, CONTROL 1 sets the wet level of Reverb A, CONTROL 2 sets the
wet level of Reverb B, and MIX sets the level of the dry signal. When routing the reverbs in
Cascade Mode, CONTROL 1 sets the wet/dry mix of Reverb A, CONTROL 2 sets the wet/dry mix
of Reverb B, and MIX sets the level of the dry signal. In A+B Mode, the TIME, PRE-DELAY and
TREBLE knobs will override the knob positions selected in steps 2 and 3.
6. Select the A/B Reverb Toggle Switch position to which you would like the Preset to initially
engage (A, B, or A+B).
7. Press and hold the SELECT/(HOLD) SAVE Button. Continue holding the SELECT/(HOLD) SAVE until
the P LED blinks fast, then slow, and eventually turns solid. This indicates that the preset
RESET
has been saved. To copy a preset from one location to another, see the
section below.
8. Note: It is also possible to route A+B Reverb Presets so that Reverb A routes exclusively to
Output 1 and only Reverb B routes exclusively to Output 2 – this is called "Independent Stereo
Mode" and it is one of the alternate routing options available via the Neuro Editor. Go to the
Neuro Sound Editor
SA262
Analog Dry Level
MIX
Reverb B Mix
Reverb
B
CONTROL 2
Digital Dry Path
LED is lit.
section for more info on Independent Stereo modes.
Ventris Dual Reverb Owner's Manual
Analog Dry Path
Reverb A Mix
Reverb
A
CONTROL 1
Digital Dry Path
1
Copying a Preset
28
