Overview

Three Analog Expression Outputs - Connect to up to three external devices using the analog
expression ports. These can be individually set up as passive potentiometers or active control
voltages.
Three Digital (MIDI) Outputs - A single hardware MIDI output (or USB MIDI output) can carry up to
three independently configurable MIDI expression signals.
Highly Configurable - All expression outputs can be independently configured to be compatible with
different expression standards. The taper, polarity, range, LFO, and other parameters can be set up
differently for each output.
USB-MIDI Interface - Class-compliant USB drivers make the Reflex plug-and-play ready for Mac and
Windows computers. The Reflex is a USB MIDI device that can be used in digital audio workstation
(DAW) software or to control software synthesizers and virtual instruments.
MIDI Recallable Presets - Save up to 128 presets and recall them at any time with a MIDI controller.
MIDI Merge - Merge MIDI input data to the output for maximum system compatibility.
Contents
Welcome .................................................................................................................................................. 1
Overview .................................................................................................................................................. 2
Quick Start ............................................................................................................................................... 3
Connections ............................................................................................................................................. 5
Basic Operation ........................................................................................................................................ 6
Controls and Configuration.................................................................................................................... 17
Footswitch ............................................................................................................................................. 19
Preset Storage and Recall ...................................................................................................................... 20
MIDI ....................................................................................................................................................... 21
USB ......................................................................................................................................................... 22
Expression Output Plug Configuration .................................................................................................. 23
Battery Compartment ............................................................................................................................ 25
Adjusting Treadle Resistance ................................................................................................................. 25
Specifications ......................................................................................................................................... 26
Troubleshooting ..................................................................................................................................... 26
Waste Disposal Notes ............................................................................................................................ 26
Warranty ................................................................................................................................................ 27
SA163 Reflex User's Guide 2
