PCI-DAS6031 & PCI-DAS6033 User's Guide

DAQ-Sync connector and pin out

Connector type
Compatible cables
Pin Signal Name
1 DS A/D START TRIGGER
2 GND
3 DS A/D STOP TRIGGER
4 GND
5 DS A/D CONVERT
6 GND
7 DS D/A UPDATE
8 GND
9 DS D/A START TRIGGER
10 GND
11 RESERVED
12 GND
13 SYNC CLK
14 GND

Main connector and pin out

Connector type
Compatible cables
Compatible accessory products
(with C100HD50-x cable)
Compatible accessory products
(with C100MMS-x cable)
Table 24. DAQ-Sync connector specifications
14-pin right-angle 100 mil box header
MCC p/n: CDS-14-x, 14-pin ribbon cable.
x = number of boards (2 - 5)
Table 25. DAQ-Sync connector pin out
Table 26. Main connector specifications
Shielded SCSI 100 D-type
C100HD50-x, unshielded ribbon cable.
x = 3 or 6 feet
C100MMS-x, shielded round cable.
x = 1, 2, or 3 meters
ISO-RACK16/P
ISO-DA02/P
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
SCB-100
BNC-16DI-FE
6-11
Specifications
