PCI-DAS6034 & PCI-DAS6035 User's Guide

2.5.3 DAQ-Sync Connector and Pin Out

Connector type
Compatible Cables
Table 2-4. DAQ-Sync Connector & Cable Types
14-Pin right-angle 100mil box header
MCC p/n: CDS-14-x, 14 pin ribbon cable for
board-to board DAQ-Sync connection; x =
number of boards (2 – 5)
Table 2-5.DAQ-Sync Connector Pinout
Pin Signal Name
1 DS A/D START TRIGGER
2 GND
3 DS A/D STOP TRIGGER
4 GND
5 DS A/D CONVERT
6 GND
7 DS D/A UPDATE
8 GND
9 DS D/A START TRIGGER
10 GND
11 RESERVED
12 GND
13 SYNC CLK
14 GND
2–7
Installation
