PCI-DAS6031 & PCI-DAS6033 User's Guide

DAQ-Sync inter-board triggers/clocks

The DAQ-Sync bus provides inter-board triggering and synchronization capability. Five trigger/strobe I/O pins
and one clock I/O pin are provided on a 14-pin header. The DAQ-Sync signals use dedicated pins. Only the
direction may be set.
DAQ-Sync signals:

Power consumption

+5 V
+5 V available at I/O connector

Environmental

Operating temperature range
Storage temperature range
Humidity

Mechanical

Card dimensions
Table 20. DAQ-Sync signals
DS A/D START TRIGGER
DS A/D STOP TRIGGER
DS A/D CONVERT
DS D/A UPDATE
DS D/A START TRIGGER
SYNC CLK
Table 21. Power consumption specifications
PCI-DAS6031/32: 1.3 A typical, 1.5 A max.
Does not include power consumed through the I/O connector.
1 A max, protected with a resettable fuse
Table 22. Environmental specifications
0 to 55 °C
-20 to 70 °C
0 to 90% non-condensing
Table 23. Mechanical Specifications
PCI half card: 174.4 mm (L) x 106.9 mm (W) x 11.65 mm (H)
6-10
Specifications
