PCI-DAS6031 & PCI-DAS6033 User's Guide
Pin Signal Name
1 LLGND
2 CH0 IN
3 CH32 IN
4 CH1 IN
5 CH33 IN
6 CH2 IN
7 CH34 IN
8 CH3 IN
9 CH35 IN
10 CH4 IN
11 CH36 IN
12 CH5 IN
13 CH37 IN
14 CH6 IN
15 CH38 IN
16 CH7 IN
17 CH39 IN
18 LLGND
19 CH8 IN
20 CH40 IN
21 CH9 IN
22 CH41 IN
23 CH10 IN
24 CH42 IN
25 CH11 IN
26 CH43 IN
27 CH12 IN
28 CH44 IN
29 CH13 IN
30 CH45 IN
31 CH14 IN
32 CH46 IN
33 CH15 IN
34 CH47 IN
35 AISENSE
36 D/A OUT 0 *
37 D/A GND
38 D/A OUT1 *
39 PC +5 V
40 AUXOUT0 / D/A PACER OUT
41 AUXOUT1 / A/D PACER OUT
42 AUXOUT2 / SCANCLK
43 AUXIN0 / A/D CONVERT / ATRIG
44 N/C
45 AUXIN1 / A/D START TRIGGER
46 AUXIN2 / A/D STOP TRIGGER
47 AUXIN3 / D/A UPDATE
48 AUXIN4 / D/A START TRIGGER
49 AUXIN5 / A/D PACER GATE
50 GND
* = N/C on PCI-DAS6033
Table 28. 64-channel single-ended mode pin out
6-13
Pin Signal Name
51 LLGND
52 CH16 IN
53 CH48 IN
54 CH17 IN
55 CH49 IN
56 CH18 IN
57 CH50 IN
58 CH19 IN
59 CH51 IN
60 CH20 IN
61 CH52 IN
62 CH21 IN
63 CH53 IN
64 CH22 IN
65 CH54 IN
66 CH23 IN
67 CH55 IN
68 LLGND
69 CH24 IN
70 CH56 IN
71 CH25 IN
72 CH57 IN
73 CH26 IN
74 CH58 IN
75 CH27 IN
76 CH59 IN
77 CH28 IN
78 CH60 IN
79 CH29 IN
80 CH61 IN
81 CH30 IN
82 CH62 IN
83 CH31 IN
84 CH63 IN
85 DIO0
86 DIO1
87 DIO2
88 DIO3
89 DIO4
90 DIO5
91 DIO6
92 DIO7
93 CTR1 CLK
94 CTR1 GATE
95 CTR1 OUT
96 GND
97 CTR2 CLK
98 CTR2 GATE
99 CTR2 OUT
100 GND
