PCI-DAS6031 & PCI-DAS6033 User's Guide
Pins 1-50 are on the long side
of the "D" connector.
50 100
1 51
50 100
1 51
Pins 51-100 are on
the short side of
the "D" connector.
Stamped "Pins 51-100".
Figure 2-1. C100HD50-x cable connections
Figure 2-2. C100MMS-x cable
Installing the PCI-DAS6031 and PCI-DAS6033
Strain relief is
stamped "Pins 1-50".
Key
Key
Strain relief is
2-7
49 50
2
1
The red stripe
identifies pin # 1
99 100
51 52
The red stripe
identifies pin # 51
50 100
1 51
