PCI-DAS6031 & PCI-DAS6033 User's Guide
Unpacking the hardware
As with any electronic device, you should take care while handling to avoid damage from static
electricity. Before removing the PCI-DAS6031 and PCI-DAS6033 from its packaging, ground yourself using a
wrist strap or by simply touching the computer chassis or other grounded object to eliminate any stored static
charge.
If any components are missing or damaged, notify Measurement Computing Corporation immediately by
phone, fax, or e-mail:
! Phone: 508-946-5100 and follow the instructions for reaching Tech Support.
! Fax: 508-946-9500 to the attention of Tech Support
! Email:
techsupport@mccdaq.com
Installing the software
Install the software included with your board before you install the hardware. Installing the software first
ensures that the information required for proper board detection is installed and available at boot up.
Refer to the Quick Start Guide for instructions on installing the software on the Measurement Computing Data
Acquisition Software CD. This booklet is available in PDF at
Quick-Start.pdf.
Installing the hardware
The PCI-DAS6031 and PCI-DAS6033 boards are completely plug-and-play, with no switches or jumpers to set.
Configuration is controlled by your system's BIOS. To install your board, follow the steps below.
Install the MCC DAQ software before you install your board
The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install the
MCC DAQ software before you install your board. Refer to the Quick Start Guide for instructions on installing
the software.
1.
Turn your computer off, open it up, and insert your board into an available PCI slot.
2.
Close your computer and turn it on.
If you are using an operating system with support for plug-and-play (such as Windows 2000 or Windows
XP), a dialog box pops up as the system loads indicating that new hardware has been detected. If the
information file for this board is not already loaded onto your PC, you will be prompted for the disk
containing this file. The MCC DAQ software contains this file. If required, insert the Measurement
Computing Data Acquisition Software CD and click
3.
To test your installation and configure your board, run the InstaCal utility you installed in the previous
section. Refer to the Quick Start Guide that came with your board for information on how to initially set up
and load InstaCal.
If your board has been powered-off for more than 10 minutes, allow your computer to warm up for at least 15
minutes before acquiring data. This warm-up period is required for the board to achieve its rated accuracy. The
high speed components used on the board generate heat, and it takes this amount of time for a board to reach
steady state if it has been powered off for a significant amount of time.
Installing the PCI-DAS6031 and PCI-DAS6033
www.mccdaq.com/PDFmanuals/DAQ-Software-
.
OK
2-2
