PCI-DAS6031 & PCI-DAS6033 User's Guide
Table 2-3.
64-channel single-ended
mode pin out
* = N/C on the PCI-DAS6033
Signal Name Pin
• •
GND 100
CTR2 OUT 99 • •
• •
CTR2 GATE 98
CTR2 CLK 97 • •
• •
GND 96
CTR1 OUT 95 • •
• •
CTR1 GATE 94
CTR1 CLK 93 • •
DIO7 92 • •
DIO6 91 • •
DIO5 90 • •
DIO4 89 • •
• •
DIO3 88
DIO2 87 • •
DIO1 86 • •
DIO0 85 • •
CH63 IN 84 • •
CH31 IN 83 • •
CH62 IN 82 • •
CH30 IN 81 • •
CH61 IN 80 • •
CH29 IN 79 • •
CH60 IN 78 • •
CH28 IN 77 • •
CH59 IN 76 • •
CH27 IN 75 • •
CH58 IN 74 • •
CH26 IN 73 • •
CH57 IN 72 • •
CH25 IN 71 • •
CH56 IN 70 • •
CH24 IN 69 • •
LLGND 68 • •
CH55 IN 67 • •
CH23 IN 66 • •
CH54 IN 65 • •
CH22 IN 64 • •
CH53 IN 63 • •
CH21 IN 62 • •
CH52 IN 61 • •
CH20 IN 60 • •
CH51 IN 59 • •
CH19 IN 58 • •
CH50 IN 57 • •
CH18 IN 56 • •
• •
CH49 IN 55
CH17 IN 54 • •
CH48 IN 53 • •
CH16 IN 52 • •
LLGND 51 • •
↓
PCI slot
Installing the PCI-DAS6031 and PCI-DAS6033
Pin Signal Name
50 GND
49 AUXIN5 / A/D PACER GATE
48 AUXIN4 / D/A START TRIGGER
47 AUXIN3 / D/A UPDATE
46 AUXIN2 / A/D STOP TRIGGER
45 AUXIN1 / A/D START TRIGGER
44 N/C
43 AUXIN0 / A/D CONVERT / ATRIG
42 AUXOUT2 / SCANCLK
41 AUXOUT1 / A/D PACER OUT
40 AUXOUT0 / D/A PACER OUT
39 PC +5 V
38 D/A OUT1 *
37 D/A GND
36 D/A OUT 0 *
35 AISENSE
34 CH47 IN
33 CH15 IN
32 CH46 IN
31 CH14 IN
30 CH45 IN
29 CH13 IN
28 CH44 IN
27 CH12 IN
26 CH43 IN
25 CH11 IN
24 CH42 IN
23 CH10 IN
22 CH41 IN
21 CH9 IN
20 CH40 IN
19 CH8 IN
18 LLGND
17 CH39 IN
16 CH7 IN
15 CH38 IN
14 CH6 IN
13 CH37 IN
12 CH5 IN
11 CH36 IN
10 CH4 IN
9 CH35 IN
8 CH3 IN
7 CH34 IN
6 CH2 IN
5 CH33 IN
4 CH1 IN
3 CH32 IN
2 CH0 IN
1 LLGND
2-6
