PCI-DAS6031 & PCI-DAS6033 User's Guide
Pinout – main
I/O connector
Table 2-2.
32-channel differential
mode pin out
* = N/C on the PCI-DAS6033
Signal Name Pin
GND 100 • •
CTR2 OUT 99 • •
CTR2 GATE 98 • •
CTR2 CLK 97 • •
• •
GND 96
CTR1 OUT 95 • •
CTR1 GATE 94 • •
CTR1 CLK 93 • •
DIO7 92 • •
DIO6 91 • •
DIO5 90 • •
DIO4 89 • •
DIO3 88 • •
DIO2 87 • •
DIO1 86 • •
DIO0 85 • •
CH31 IN LO 84 • •
CH31 IN HI 83 • •
CH30 IN LO 82 • •
CH30 IN HI 81 • •
CH29 IN LO 80 • •
CH29 IN HI 79 • •
CH28 IN LO 78 • •
CH28 IN HI 77 • •
CH27 IN LO 76 • •
CH27 IN HI 75 • •
CH26 IN LO 74 • •
CH26 IN HI 73 • •
CH25 IN LO 72 • •
CH25 IN HI 71 • •
CH24 IN LO 70 • •
CH24 IN HI 69 • •
LLGND 68 • •
CH23 IN LO 67 • •
CH23 IN HI 66 • •
CH22 IN LO 65 • •
CH22 IN HI 64 • •
• •
CH21 IN LO 63
CH21 IN HI 62 • •
CH20 IN LO 61 • •
CH20 IN HI 60 • •
CH19 IN LO 59 • •
CH19 IN HI 58 • •
• •
CH18 IN LO 57
CH18 IN HI 56 • •
• •
CH17 IN LO 55
CH17 IN HI 54 • •
• •
CH16 IN LO 53
CH16 IN HI 52 • •
• •
LLGND 51
↓
PCI slot
Installing the PCI-DAS6031 and PCI-DAS6033
Pin Signal Name
50 GND
49 AUXIN5 / A/D PACER GATE
48 AUXIN4 / D/A START TRIGGER
47 AUXIN3 / D/A UPDATE
46 AUXIN2 / A/D STOP TRIGGER
45 AUXIN1 / A/D START TRIGGER
44 N/C
43 AUXIN0 / A/D CONVERT / ATRIG
42 AUXOUT2 / SCANCLK
41 AUXOUT1 / A/D PACER OUT
40 AUXOUT0 / D/A PACER OUT
39 PC +5 V
38 D/A OUT1 *
37 D/A GND
36 D/A OUT 0 *
35 AISENSE
34 CH15 IN LO
33 CH15 IN HI
32 CH14 IN LO
31 CH14 IN HI
30 CH13 IN LO
29 CH13 IN HI
28 CH12 IN LO
27 CH12 IN HI
26 CH11 IN LO
25 CH11 IN HI
24 CH10 IN LO
23 CH10 IN HI
22 CH9 IN LO
21 CH9 IN HI
20 CH8 IN LO
19 CH8 IN HI
18 LLGND
17 CH7 IN LO
16 CH7 IN HI
15 CH6 IN LO
14 CH6 IN HI
13 CH5 IN LO
12 CH5 IN HI
11 CH4 IN LO
10 CH4 IN HI
9 CH3 IN LO
8 CH3 IN HI
7 CH2 IN LO
6 CH2 IN HI
5 CH1 IN LO
4 CH1 IN HI
3 CH0 IN LO
2 CH0 IN HI
1 LLGND
