PCI-DAS6402/16 User's Guide
Caution! When connecting a cable to the board's I/O connector, make sure that the arrow indicating pin 1
on the board connector lines up with the arrow indicating pin 1 on the cable connector. Incorrectly
connected cables can damage the board and the I/O controller.
Pinout – main I/O connector
EXTERNAL D/A TRIGGER/PACER GATE
D/A EXTERNAL PACER INPUT
A/D INTERNAL PACER OUTPUT
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Table 2-2. . 32-channel differential mode pin out
Signal Name Pin
GND 100
EXTERNAL INTERRUPT 99
A/D PACER GATE 98
97
96
95
DIN3 94
DIN2 93
-12 V 92
GND 91
+12 V 90
GND 89
DOUT3 88
DOUT2 87
DOUT1 86
DOUT0 85
CH31 LO 84
CH31 HI 83
CH30 LO 82
CH30 HI 81
CH29 LO 80
CH29 HI 79
CH28 LO 78
CH28 HI 77
CH27 LO 76
CH27 HI 75
CH26 LO 74
CH26 HI 73
CH25 LO 72
CH25 HI 71
CH24 LO 70
CH24 HI 69
LLGND 68
CH23 LO 67
CH23 HI 66
CH22 LO 65
CH22 HI 64
CH21 LO 63
CH21 HI 62
CH20 LO 61
CH20 HI 60
CH19 LO 59
CH19 HI 58
CH18 LO 57
CH18 HI 56
CH17 LO 55
CH17 HI 54
CH16 LO 53
CH16 HI 52
LLGND 51
↓
PCI slot
2-4
Installing the PCI-DAS6402/16
Pin Signal Name
• • 50 GND
• • 49 SSH OUT/DAC PACER OUT
• • 48 PC +5 V
• •
47 A/D STOP TRIGGER IN
• • 46 DIN1
• • 45 A/D START TRIGGER IN
• • 44 DIN0
• • 43 ANALOG TRIGGER IN
• • 42 A/D EXTERNAL PACER
• •
41 CTR1 OUT
• • 40 CTR1 GATE
• • 39 CTR1 CLK
• • 38 D/A OUT 1
• • 37 D/A GND 1
• •
36 D/A OUT 0
• • 35 D/A GND 0
• • 34 CH15 LO
• • 33 CH15 HI
• • 32 CH14 LO
• •
31 CH14 HI
• •
30 CH13 LO
• • 29 CH13 HI
• • 28 CH12 LO
• • 27 CH12 HI
• • 26 CH11 LO
• •
25 CH11 HI
• • 24 CH10 LO
• • 23 CH10 HI
• • 22 CH9 LO
• • 21 CH9 HI
• •
20 CH8 LO
• • 19 CH8 HI
• • 18 LLGND
• • 17 CH7 LO
• • 16 CH7 HI
• •
15 CH6 LO
• • 14 CH6 HI
• • 13 CH5 LO
• • 12 CH5 HI
• • 11 CH4 LO
• •
10 CH4 HI
• • 9 CH3 LO
• • 8 CH3 HI
• • 7 CH2 LO
• • 6 CH2 HI
• •
5 CH1 LO
• •
4 CH1 HI
• • 3 CH0 LO
• • 2 CH0 HI
• • 1 LLGND
