Appendices
154
CT Mode (Xmaru1524CF Master Plus)
Tested Mode
Applied Tube Voltage Peak [kVp]
Applied Tube Current [mA]
Mode
Direction [°]
0
45
90
135
180
225
270
315
Test Condition
CT FOV 160 x 100
High Resolution Mode 9.0s
FOV 160 x 100 9.0 s [mR]
1 m
1.5 m
(3.3 ft)
(4.9 ft)
1.727
0.971
1.817
0.952
0.656
0.170
2.392
1.121
2.541
1.104
2.399
1.095
2.415
1.185
1.874
0.936
PaX-i3D Green (PHT-60CFO) User Manual
99
14
2 m
(6.6 ft)
0.482
0.499
0.044
0.525
0.480
0.500
0.581
0.467
