X-Ray Leakage Dose - Vatech PaX-i3D User Manual

Appendices
2.2
152

X-ray Leakage Dose

Instrument
Radiation Monitor
Controller
Test Condition
Test mode
PANO/ Adult
CEPH/ 12x10(in.)
CT/ 16x10(cm)
CT/ 15x15(cm)
Mode
Direction [°]
0
45
90
100
110
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
315
Test Equipment
Manufacturer Model
Radcal 9015
Detector
Xmaru 1501CF
1210SGA
Xmaru 1524CF Master Plus
Xmaru 1524CF Master Plus
PANO / CEPH /
Adult 12x10(in.)
1.1 5.1
3.5 14.2
5.8 18.2
7.3 14.3
4.7 15.2
3.9 22.4
12.7 51.2
20.7 45.1
24.5 57.4
22.4 51.1
15.1 33.7
10.5 33
5.9 21.4
3.2 12.9
2.8 4.3
3.2 2.7
3.6 5.5
4.2 8.2
6.8 29.7
4.9 33.3
19.6 42.1
3.4 9.4
PaX-i3D Green (PHT-60CFO) User Manual
S/N
91-1470/19069
kVP mA
80 16
99 14
99 14
99 14
CT /
16x10(cm) 15x15(cm)
[mR/hr]
5.2
14.6
17.0
16.0
11.7
20.3
45.1
48.7
58.1
52.8
33.5
23.8
18.2
14.2
9.0
7.4
8.5
8.3
23.2
33.3
50.7
12.4
sec
13.5
0.7
9.0
9.0
CT /
4.8
4.3
12.0
7.8
8.0
12.3
35.1
36.8
17.4
41.0
16.4
16.0
5.5
14.0
3.3
5.6
2.6
4.1
21.7
18.7
25.7
11.2
