Quick Start

1. Connect video source to transmitter HDMI IN
2. Connect display technology to receiver HDMI OUT
3. Connect transmitter and receiver together with a shielded Category 6 cable
4. Connect control (optional)
5. Connect Ethernet (optional)
6. Apply power to either transmitter OR receiver to power entire circuit

Connecting a Video Source

HDMI Input (Transmitter)

Connect an HDMI source device to the HDMI input on the DL-HDE100 transmitter labeled HDMI IN using an
HDMI cable that is less than or equal to 5 meters in total length. For HDMI source devices that are further away,
an active HDMI cable may be required to complete the connection.

Connecting a Display

HDMI Output (Receiver)

Connect the display to the HDMI output on the DL-HDE100 receiver labeled HDMI OUT using an HDMI cable
that is less than or equal to 5 meters in length. It is recommended to keep the DL-HDE100 receiver near the
display input as it is not recommended that an active HDMI cable be used on the HDMI output on the DL-
HDE100 receiver.
