DL-HD70LS Quick Install Guide
For complete owners manual go to www.libav.com or use a QR reader to access the
Important notice:
• Do not attempt to disassemble or alter the housing. There are no user-serviceable parts
inside the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic discharge (ESD), all source and destination
equipment must be powered off during installation.
• Do not connect the device to a telecommunication outlet wired to unrelated equipment. Doing so may
damage the unit or any connected equipment. Ensure all connected twisted pair cabling is straight-through (point-
to-point).
• Allow proper ventilation to reduce the risk of thermal failure.
This guide is for quick installation only.
manual via QR code below.
Scan QR Code with your Smart-phone or Tablet
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DigitaLinx DL-HD70LS
Summary of Contents for DigitaLinx DL-HD70LS
- Page 1 DL-HD70LS Quick Install Guide This guide is for quick installation only. For complete owners manual go to www.libav.com or use a QR reader to access the manual via QR code below. Scan QR Code with your Smart-phone or Tablet Important notice: •...
-
Page 2: Product Overview
Built-in surge protection helps ensure hassle-free and robust installations. The 12 volt power supply is secured with a screw-on connector to prevent the power from being accidentally disconnected. The DL-HD70LS is sold only as a set. The individual transmitter and receiver are not compatible with other HDBaseT devices due to proprietary PoE circuitry. -
Page 3: Transmitter View
Transmitter View HDMI INPUT SIDE TWISTED PAIR OUTPUT SIDE HDMI IN • HDMI input port for connections to video sources IR IN • 3.5mm IR input port for connection to IR receiver or IR system IR OUT • 3.5mm IR input port for connection to IR receiver or IR system Power Indicator •... - Page 4 Receiver View HDMI OUTPUT SIDE TWISTED PAIR INPUT SIDE HDMI OUT • HDMI output port for connections to display devices IR IN • 3.5mm IR input port for connection to IR receiver or IR system IR OUT • 3.5mm IR input port for connection to IR receiver or IR system Power Indicator •...
- Page 5 8. Power on attached audio/video devices. Passing IR Signals: The DL-HD70LS is capable of passing IR signals between 33 and 55 KHz. To prevent damage to any of the electronics, the extenders should be powered off while inserting or removing any IR components. Inserting an IR transmitter into the IR IN port may damage the IR circuit for that extender.
-
Page 6: Cabling Requirements
Cabling Requirements HDBaseT Cabling To ensure proper performance of the DL-HD70LS, it is recommended that you use solid core, shielded Category 6 F/UTP cabling at a minimum. Category 5e F/UTP may perform well but may not support power over HDBaseT reliably. -
Page 7: Technical Specifications
Technical Specifications Supported Audio and Video Maximum Video Compatibility 70 m: Deep Color 36/30/24 Bit at 1080p 40 m: Deep Color 48 Bit at 1080p, 3D, and 4k x 2k (UHD) Video Compliance HDMI, HDCP, and CEC (Consumer Electronics Control) Embedded Audio Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio IR Carrier Frequency Range... - Page 8 Thank you for your purchase. For Technical Support please call our toll free number at 800-530-8898 or email us at supportlibav@libav.com www.intelix.com www.libav.com is a brand of: 11675 Ridgeline Drive Colorado Springs, Colorado 80921 USA Phone: 719-260-0061 Fax: 719-260-0075 Toll-Free: 800-530-8998...
