DigitaLinx DL-HDE100 Quick Install Manual

Extender set transmits hdmi, bidirectional ir, rs232 and ethernet up to 100 meters away using a single category 6 twisted pair cable.
Hide thumbs Also See for DL-HDE100:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Installation Manual
DL-HDE100 Quick Install Guide
For complete owners manual go to www.libav.com or use a QR reader to access the
Important notice:
• Do not attempt to disassemble or alter the housing. There are no user-serviceable parts
inside the unit. Doing so will void your warranty.
• To minimize the possibility of equipment damage from electrostatic discharge (ESD), all source and destination
equipment must be powered off during installation.
• Do not connect the device to a telecommunication outlet wired to unrelated equipment. Doing so may
damage the unit or any connected equipment. Ensure all connected twisted pair cabling is straight-through (point-
to-point).
• Allow proper ventilation to reduce the risk of thermal failure.
This guide is for quick installation only.
manual via QR code below.
Scan QR Code with your Smart-phone or Tablet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DL-HDE100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DigitaLinx DL-HDE100

Summary of Contents for DigitaLinx DL-HDE100

  • Page 1 DL-HDE100 Quick Install Guide This guide is for quick installation only. For complete owners manual go to www.libav.com or use a QR reader to access the manual via QR code below. Scan QR Code with your Smart-phone or Tablet Important notice: •...

  • Page 2: Product Overview

    The 18 volt power supply is secured with a screw-on connector to prevent the power from being accidentally disconnected. The DL-HDE100 is sold only as a set. The individual transmitter and receiver are not compatible with other HDBaseT devices due to proprietary PoE circuitry.

  • Page 3: Transmitter View

    The DL-HDE100 provides four blue LEDs to indicate the current operating status and to assist troubleshooting an installation. Power: Solid, the DL-HDE100 extender is receiving power from the power supply or from the remote extender via Category 6 cabling. Status: Flashes once per second, the HDBaseT processor is running.

  • Page 4: Receiver View

    The DL-HDE100 provides four blue LEDs to indicate the current operating status and to assist troubleshooting an installation. Power: Solid, the DL-HDE100 extender is receiving power from the power supply or from the remote extender via Category 6 cabling. Status: Flashes once per second, the HDBaseT processor is running.
  • Page 5 8. Power on attached audio/video devices. Passing IR Signals: The DL-HDE100 is capable of passing IR signals between 33 and 55 KHz. To prevent damage to any of the electronics, the extenders should be powered off while inserting or removing any IR components. Inserting an IR transmitter into the IR IN port may damage the IR circuit for that extender.

  • Page 6: Cabling Requirements

    P n 6 Green P n 7 Brown/Wh te P n 8 Brown RS232 Wiring Connect the controller or device RX signal to TX on the DL- extender. Connect the HDE100 controller or device TX signal to Rx on the DL-HDE100 extender.

  • Page 7: Technical Specifications

    Technical Specifications Supported Audio and Video Maximum Video Compatibility 100 m; Deep Color 36/30/24 Bit at 1080p 70 m; Deep Color 48 bit at 1080p, 3D and UHD Video Compliance HDMI 2.0, HDCP 2.2, and CEC (Consumer Electronics Control) Embedded Audio Up to PCM 8 channel, Dolby Digital TrueHD, and DTS-HD Master Audio IR Carrier Frequency Range 33-55kHz at 5 volts...
  • Page 8 Thank you for your purchase. For Technical Support please call our toll free number at 800-530-8898 or email us at supportlibav@libav.com www.intelix.com www.libav.com is a brand of: 11675 Ridgeline Drive Colorado Springs, Colorado 80921 USA Phone: 719-260-0061 Fax: 719-260-0075 Toll-Free: 800-530-8998...
