LOGIQ 7 Quick Guide

Exporting Patient Data

Format a CD/MOD prior to following these steps.

1. Press Patient. Deselect any selected patient(s)

in the search portion of the Patient screen.

Press More (located at the lower, right-hand

corner of the Patient menu).

2. Select Export. Specify the type of removable

media (MOD or CD-ROM) on the Export pop-

up. Press OK. Then, please wait until the

Patient menu is visible.

3. In the patient list at the bottom of the Patient

menu, select the patient(s) you want to export.

NOTE: You can use Windows commands to

select more than one patient.

NOTE: You need to use your best judgment

when moving patients' images. If there are lots

of images or loops, then only move a few

patients at a time.

4. Once you have selected all of the patients to

export, press Copy Patient from the Select All/

Copy Patient Menu.

5. Informational status messages appear as the

copy is taking place. A final status report pop-

up message appears. Press OK.

6. Press F3 to eject the CD or press the MOD

eject button. Specify that you want to finalize

the CD-ROM.

Image/ Patient Management

Direction 2291859-100 Rev. 1

Importing Patient Data/Images

1. At another Ultrasound system, insert the MOD

or CD-ROM.

2. Press Patient, press More, then Import. The

Import From pop-up message appears. Press

OK.

3. The Patient menu just shows the patients

available for import from the removable media

you just loaded onto the system.

4. Select the patients to be imported.

5. Press Copy Patient from the Select All/Copy

Patient menu.

6. Please wait for the patient information to be

copied to this Ultrasound system. Informational

messages appear while the import is taking

place.

7. Press F3 to eject the media.

and Connectivity

Connectivity

Connectivity on the LOGIQ 7 is based on the
