LOGIQ 7 Quick Guide

Using CINE

Activating CINE
Press Freeze, then roll the Trackball to activate
CINE. To start CINE Loop playback, press Run/
Stop. To stop CINE Loop playback. press Run/Stop.
To activate Timeline CINE, press Freeze, press
Scan Area, then roll the Trackball to activate
CINE.
Quickly Move to Start/End Frame
Press First to move to the first CINE frame; press
Last to move to the last CINE frame.
Direction 2291859-100 Rev. 1
Start Frame/End Frame
Turn the Start Frame dial to the left to move to the
beginning of the CINE Loop. Turn the dial to the
right to move forward through the CINE Loop.
Turn the End Frame dial to the right to move to the
end of the CINE Loop. Turn the dial to the left to
move backward through the CINE Loop.
Adjusting the CINE Loop Playback Speed
Turn the Loop Speed dial clockwise/counter-
clockwise to increase/decrease the CINE Loop
playback speed.
Disconnecting B-Mode CINE from Timeline
CINE
To review the B-Mode CINE Loop only, press Cine
Mode Selection and select B Only.
To review the Timeline CINE Loop only, press Cine
Mode Selection and select TL Only.
To return to linked B-Mode and Timeline CINE Loop
review, press Cine Mode Selection and select
B/TL.
Moving through a CINE Loop Frame By
Frame
Turn Frame by Frame to move through CINE
memory one frame at a time.
