LOGIQ 7 Quick Guide

Patient Environmental Devices

1. Peripheral Device (Signals I/O Port, Power In)
2. Front Panel (Signal I/O Port, Power Out)
3. Non-Imaging Probes
4. Imaging Probes
5. Probe Port
6. ECG Cable
7. PCG Sensor
8. Physio-Signal Input Panel
9. Rear Panel
Safety
Direction 2291859-100 Rev. 1
1
2
6
13
8
7
24
20
25
3
5
4
Figure 1-1. Patient Environmental Devices
10. Signals I/O Port
11. Power Out
12. Signals I/O Port
13. Footswitch Connector
14. Power In
15. Peripheral Devices
16. Signals I/O Port
17. Power In
18. InSite Modem (Signal I/O Port)
15
9
10
16
11
17
12
18
19
14
21
22
23
19. Power Telephone Line
20. Footswitch
21. Power Line (AC~)
22. Ground Line
23. Power Cable with Protective Earth
24. MO Drive
25. CD-RW
47
