LOGIQ 7 Quick Guide
Label/Icon
"ON" indicates the power on position of the power switch.
CAUTION: This Power Switch DOES NOT ISOLATE Mains Supply.
"Standby" indicates the power standby position of the power switch.
CAUTION: This Power Switch DOES NOT ISOLATE Mains Supply.
"Protective Earth" indicates the protective earth (grounding) terminal.
"Equipotentiality" indicates the terminal to be used for connecting equipotential conductors when
interconnecting (grounding) with other equipment.
Safety
Direction 2291859-100 Rev. 1
Table 1-2: Label Icons
Purpose/Meaning
Location
Refer to Chapter 3 in the Basic User Manual for
location information.
Internal
Rear of console
39
