CHAPTER 5: SETTINGS
The C60 maintains two times: local time and Universal Coordinated Time (UTC). Local time can be provided by IRIG-B
signals. UTC time is provided by SNTP servers.
The real-time clock (RTC) and time stamps reported in historical records and communication protocols can be incorrect if
the Local Time settings are not configured properly.
See the IRIG-B section in the Installation chapter for guidance on these settings when using an IRIG-B source that sets the
IRIG-B control bits according to IEEE Std 1344-1995.
LOCAL TIME OFFSET FROM UTC
zones in the eastern hemisphere have positive values; time zones in the western hemisphere have negative values. A value
of zero causes the relay to use UTC for local time. This setting has two uses. When the system RTC is synchronized with a
communications protocol providing only local time or it is free-running, the offset setting is used to calculate UTC from the
local time these provide. When the RTC is synchronized with a communications protocol providing only UTC (such as PTP or
SNTP), the time offset setting is used to determine local time from the UTC provided. PTP
ALTERNATE_TIME_OFFSET_INDICATOR TLVs are not used to calculate local time.
and
DAYLIGHT SAVINGS TIME DST
when IRIG-B time synchronization is active, the local time in the IRIG-B signal contains any daylight savings time offset and
so the DST settings are ignored.

5.3.8 Fault reports

SETTINGS  PRODUCT SETUP  FAULT REPORTS  FAULT REPORT 1(4)
 FAULT REPORT 1

C60 BREAKER PROTECTION SYSTEM – INSTRUCTION MANUAL
DST START DAY:

Sunday
DST START DAY

INSTANCE: First
DST START HOUR:

2:00
DST STOP MONTH:

January
DST STOP DAY:

Sunday
DST STOP DAY

INSTANCE: First
DST STOP HOUR:

2:00
— Used to specify the local time zone offset from UTC (Greenwich Mean Time) in hours. Time
— Can be used to allow the relay to follow the DST rules of the local time zone. Note that
FAULT REPORT 1

SOURCE: SRC 1
FAULT REPORT 1 TRIG:

Off
FAULT REPORT 1 Z1

MAG: 3.00 Ω
FAULT REPORT 1 Z1

ANGLE: 75°
FAULT REPORT 1 Z0

MAG: 9.00 Ω
FAULT REPORT 1 Z0

ANGLE: 75°
FAULT REPORT 1 Z0M

MAG: 0.00 Ω
Range: Sunday to Saturday (all days of the week)
Range: First, Second, Third, Fourth, Last
Range: 0:00 to 23:00 in steps of one hour
Range: January to December (all months)
Range: Sunday to Saturday (all days of the week)
Range: First, Second, Third, Fourth, Last
Range: 0:00 to 23:00 in steps of one hour
Range: SRC 1, SRC 2, SRC 3, SRC 4
Range: FlexLogic operand
Range: 0.01 to 250.00 ohms in steps of 0.01
Range: 25 to 90° in steps of 1
Range: 0.01 to 650.00 ohms in steps of 0.01
Range: 25 to 90° in steps of 1
Range: 0.00 to 650.00 ohms in steps of 0.01
