GEK-655258
INSTRUCTIONS
THREE-PHASE POWER-DIRECTIONAL RELAY
TYPE CCP13E
GE Meter and Control
Great Valley Parkway
205
Malvern, PA
19355-0715

Advertisement

Table of Contents
loading

Summary of Contents for GE CCP13E

  • Page 1 GEK-655258 INSTRUCTIONS THREE-PHASE POWER-DIRECTIONAL RELAY TYPE CCP13E GE Meter and Control Great Valley Parkway Malvern, PA 19355-0715...
  • Page 2: Table Of Contents

    GEK-65525 CONTENTS PAGE DESCRIPTION • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •...
  • Page 3: Description

    There is a target and seal-in coil in series with the normally-open contact. The CCP13E relay is functionally equivalent to the CCP13D relay, but the two relays are not electrically interchangeable. There are differences in the output circuit arrangement s.
  • Page 4 GEK-65525 S AMPLE CALCULATIONS Consider the system illustrated in Figure 1 having the following transformer ratings: 10, 000 KVA 13, 800 Volts wye/138, 000 Volts delta Core losses = 15.0 KW at Rated Voltage The full load current at 13, 800 volts is 10, 000 = 418 Primary Amperes.
  • Page 5: Construction

    GEK-65525 CONSTRUCT! ON The type CCP13E relay is mounted in an M2-size case. The case has studs at both The outline and panel drilling for this ends in the rear for external connections. case is shown in Figure 3. The electrical connections between the relay units and the case studs are made through stationary molded inner and outer blocks, between which nests a removable connection plug that completes the circuits.
  • Page 6: Ratings

    GEK-65525 A stainless ball is placed in the tube before the diaphragm is assembled. When the moving contact hits the stationary contact, the energy of the former is imparted to the latter and then to the ball, which is free to roll up the inclined tube. Thus, the moving contact comes to rest with substantially no rebound or vibration.
  • Page 8: Acceptance Tests

    GEK-65525 ACCEPTANCE TESTS Immediately upon receipt of the relay, an inspection and acceptance test should be made to make sure that no damage has been sustained in shipment and that the relay If the examination or test indicates that calibrations have not been disturbed. readjustment is necessary, refer to the section on SERVICING.
  • Page 9: Drawout Relays, General

    (front view). Pickup The pickup of the CCP13E relay may be checked by applying rated voltage and frequency to the relay as in Figure 11. The relay should close its left contact at the current specified on the nameplate (relays are shipped with current pickup set to the minimum setting) multiplied by 1.15.
  • Page 10: High-Seismic Target And Seal-In Unit

    The outline and panel-drilling dimens ion s are shown in Figure 3. The internal connections of the CCP13E are shown in Figure 5. An elementary diagram of typical external connections is shown in Figure 2. One of the mountin g studs or screws should be permanently grounded by a conductor...
  • Page 12: Relay Contacts

    GEK-65525 SERVICING If it is found during installation or periodic testing that the relay is out of calibration, recalibrate as follows: RELAY CONTACTS Checks and Adjustments The clearance between (a) the back of the silver stationary contact mounted on the flat spiral, and (b) the diaphragm behind it, should be 0.004 inch to 0.009 inch.
  • Page 13: Bearings

    GEK-65525 BEARINGS The lower jewel screw can be removed from the unit by means of an offset screwdriver or an end wrench. The jewel may be tested for cracks by exploring its surface with the point of a fine needle. If it is necessary to replace the jewel, a new pivot should be screwed into the bottom of the shaft at the same time.
  • Page 14: Pickup Adjustment

    GEK-65525 not move at a phase angle circuit resistor is adjusted so that the contact will meter reading of 120 0 or 3QQO (angles of zero torque). The relay should close its This test is performed by left contact at all angles between 1200 and 3000 . one unit at a time.
  • Page 17 POTENTIAL CIRCUITS. POSSIBLE NOTE SWITCH IS PROVIDED TO BREAK UP A SNEAK CIRCUIT . AS AN ALTERN ATIVE> USE A DIODE LOCATION SHOWN. Figure 2 (0275A4413-4) Typical External Connections for Type CCP13E Relay Revi sed sinc e last issu e...
  • Page 18 FRONT VIEW FOR SEMI-FLUSH MOUNTING FRONT VIEW 5/16-18 STUD -� 76MM TYPICAL DIM. ASSEMBLY VIE\J SHO\JING OF HARDWARE INCHES FOR SURFACE MTG. ON STEEL PANELS * Figure (K6209274-6) Outline and Panel Drilling Dimensions Diagramfor Type CCP13E Relay Revised since last issue...
  • Page 19 .,., ..""5 CONNECTING PLUG MA IN BRUSH CONNECTING BLOCK .j:::o ..t.TI ("") ""5 1'1'1 ;<:; ,__. n 1.1'1 I.D c-T ..1.1'1 � 1.1'1 """"' ("") A UXIL IARY BRUSH TERM INAL BLOCK SHORT ING BAR �...
  • Page 20 GEK-65525 � � R�SISTORS *=SHORT FINGER Figure 5 0275A4384 Type CCP13E Relay Internal Connections...
  • Page 21 GEK-65525 A- INCLINED TUBE ·SPACER B- STA.I N LESS STEEL BALL C-D!APHRAM F-FLAT 5P!RAL SPRING G- CONTACT Barrel-Type Contact Assembly Figure 6 (6077069-4)
  • Page 22 GEK-65525 K6556481-1 Phase Angle Characteristics of Type CCP13E Relay when Set Figure 7 for 0.004 Amp pickup at Rated Voltage and Maximum Torque Angle...
  • Page 23 . GEK-65525 TARGET BARREL TYPE CONTACT ASS EM BL Y TOP UNIT MIDDLE UNIT BOTTOM UNIT Figure 8 (8043506) Type CCP13E Relay, Removed from Case, Front View...
  • Page 25 GEK-65525 RATED RATED VOLTAGE VOLTAGE RES. TO F UN IT MIDDLE UNIT RATED VOLTAGE BOTTOM UNIT 50-100 OHMS. NOTE = LEFT-HAND CONTACT, (FRONT VIEW) SHOULD C L OSE Figure 10 (6507918) Connections for checking the polarity of Type CCP13E Relay...
  • Page 26 GEK-6552 5 RATED VOLTAGE AND FREQUENCY LOAD Figure 11 (0104A8511) Test Connections for Checking Pickup and Clutch Adjustments of Type CCP13E Relay...
  • Page 27 READS THE ANGLE BY WHIOi I LEADS POWER CONNECTIONS RE.LAY ADJUST. CURRENT POTENTIAL UNIT RESISTOR STUDS STUDS C-D 13 - 14 15-16 Ml DOLE 17-18 BOTIOM Figure 12 (0104A8512) Test Connections for Making the Torque Adjustments of the Type CCP13E Relay...
  • Page 28 PHASE ANGLE METERS. * AS DETERMINED F ROM INSTRUMENTS READING POWER INTO BUS FROM THE POWER SYSTEM. NEGATIVE SIGN FOR LAG . POSITIVE SIGN FOR LEAD. Figure 13 0104A8513 Test Connections for Checking Polarity of Windings to the Type CCP13E Relay...
