The treadle can be used to sweep through beat division values. For example, if the Min is set to 1-2
(eighth note) and the max is set to 1-4 (sixteenth note), then the treadle will sweep between eighth
notes (heel down), triplets (middle position), and sixteenth notes (toe down). For more information,
refer to MIDI Clock Synchronization.
LFO Depth Parameter
When an LFO is active for a given expression output, the Depth parameter controls the amplitude of
the expression output. The output is always centered at 64, and the depth parameter dictates how
far from that center value the LFO will deviate. At maximum depth (64), for example, the output is
centered at 64 and ranges from 0 to 127.
Negative depth values invert the shape of the LFO. At a minimum depth (-64), the output is centered
at 64 and ranges from 0 to 127.
SA163
127
64
0
127
64
0
Reflex User's Guide
Time
Time
