The following figure shows an example where the Min has been increased from 0 to 20, and the Max
has been decreased from 127 to 90, resulting in an output range of 20 to 90.
127
90
20
0
Heel Heel
Toe Toe
Treadle Position Treadle Position
Taper Depth Parameter
When a taper is active for a given expression output, the Depth parameter sets whether the
expression output is inverted or not. It only has two possible values: 64 and -63. When the Depth is
set to 64, the output range is not inverted. When the Depth is set to -63, the output range is
inverted.
The following figure shows an example where the Min is set to 20, the Max is set to 90, and the
Depth is set to 64 (no inversion):
90
20
Heel
Toe
Treadle Position
