The following figure shows an example where the Min parameter has been raised from 0 to 30, so
that the expression output is now limited to the range between 30 and 127.
127
0
Heel
Treadle Position
Taper Max Parameter
When a taper is active for a given expression output, the Max parameter controls the maximum
value which is output when the treadle is in the toe down position (except when the depth of the
taper is inverted). By default, the Max parameter is set to 127, meaning that the expression output
ranges from 0 to 127. If the Max parameter is decreased, then the range of the expression output is
decreased. The following figure shows an example where the Max parameter has been lowered from
127 to 90, so that the expression output is now limited to the range between 0 and 90.
127
0
Heel
Treadle Position
The Min parameter must always be less than or equal to the Max parameter.
It is possible to lower the Max parameter and raise the Min parameter, resulting in an even smaller
expression output range.
SA163
Toe
Toe
Reflex User's Guide
127
30
Heel
Toe
Treadle Position
90
0
Heel
Toe
Treadle Position
