The following figure shows an example where the Min is set to 20, the Max is set to 90, and the
Depth is set to -63 (the output is inverted):
90
20
Heel
Toe
Treadle Position
Low Frequency Oscillators (LFOs)
There are five built-in low frequency oscillators (LFOs) which can be used to modulate the expression
output periodically with a certain wave shape. When an LFO is active, the position of the treadle
controls the frequency, or rate, of the LFO.
Sine LFO
The sine LFO follows the typical sine shape that is widely used in modulation effects such as chorus
and phaser.
Time
SA163
Reflex User's Guide
11
