Power supply units, pin assignment, power supply
Power supply
DC power pack
12/24/48 VDC
(wide-range power
supply unit)
60 W / 80 W internal
Type DC-16
Voltage range
Bridged power failures
Maximum output power
Nominal current
Connection to SELV
circuit only
Power consumption
DLT-V8310
DLT-V8312
DLT-V8315
Power supply unit fuses
Power supply unit
DC-16
The symbol for the fuse is FA.
You will find the exact position on the sticker located on the connection plate of the
DLT-V83.
Page 90 of 178
12/24/48 VDC nominal
Galvanically isolated
Withstands bursts up to 2 kV
Full output power of the 12/24/48 VDC power supply unit
for 20 seconds each:
For 6 V: 40 W
For 9 V: 60 W
Rising in linear fashion between the above
9 to 60 VDC
Typically 2 ms at 12 V
Typically 10 ms at 24 V
Typically 40 ms at 48 V
60 W (+10 to +70 °C internal device temperature);
or 80 W (-30 to +10 °C internal device temperature)
8.4 A
The SELV circuit is a secondary circuit that is designed
and protected so that its voltages will not exceed a safe
value both when operating correctly or if a single error
occurs.
Typically 25 W; standby typically 1 W
Typically 30 W; standby typically 1 W
Typically 30 W; standby typically 1 W
Fuse type Example
5 x 20 mm T Schurter 0001.2515
12.5 A
Siba 179200.12,5
H / 250 V
or similar produced by other manufacturers
