5.4.2.

Function of the front keys

The keys are backlit in blue when the device is switched on.
When the key is pressed, the lighting switches briefly to white.
Keys and LED, left on the device:
Key
LED
Advantech-DLoG
Explanation
<Power> button, switch device on/off:
To do this, press and hold the button for 2 seconds
After the device has been switched off, it can only be switched
on again after 10 seconds.
Manual brightness control: Display brighter
Manual brightness control: Display darker
Switch the backlight on/off
Note: The DLT-V83 will continue to react to keyboard, mouse
and touchscreen inputs even if the backlight is switched off.
The key glows white when the backlight is switched off
The backlight can also be switched on using the "Display
brighter" key.
Explanation
Access to storage medium (backlit green when active)
DLT-V83 Series Manual V1.31
Operating the touchscreen, front keys
Page 41 of 178
