IPEX2002 Front Panel
1
2
1.
Power indicator
2.
Status indicator
IPEX2002 Rear Panel
A
A.
12V DC power input
B.
HDMI input
C.
Local HDMI output
D.
Analog audio output
E.
RS232 connection
F.
Ground screw
B
C
IPEX2000 Series Quick Install Guide
D
E
F
