Cycle 1
Set Point Temperature
and Dwell Time
Ramp Up
Graphical
Representation
Repeats
Increase time by 00:15 every repeat.
"
Ramp Down
Advanced Option
Description
4.5 Viewing Protocols
You may view any protocol in the Protocol Library on the View screen, which
displays a graphical representation of the protocol. While viewing the protocol, you may
use the arrow keys and the Enter key to scroll through the protocol display. In addition,
a textual display of any increment or decrement option for the currently selected
parameter is shown at the bottom of the screen. Generally, the View screen serves
only as a means to browse through an existing protocol. Therefore, no modifications
can be made on the View screen.
4.5.1 Soft Key Functions for the View Screen
Softkey
Option
Description
F1
F2
F3
F4
F5
«Cycle
»Cycle
Run Screen
Home Screen
Done
Shifts the protocol display to the left by one
cycle
Shifts the protocol display to the right by one
cycle
Displays the Run screen
Displays the Home screen
Closes the View screen display
-
,~
—-
16
