16. SETUP EXAMPLES

The Digitone likes to play with other machines. Whether it uses its ability to sync and play with legacy ma-
chines, is paired with the Digitone or controls other synthesizers.

16.1 DIGITONE WITH A MONOPHONIC BASS MACHINE

MAIN OUT TO MIXER
The DIN sync capabilities of the Digitone allows you to use gear from yesteryear.
In this example, a legacy monophonic bass machine is used alongside the Digitone. The Digitone can stop,
start and control the tempo of the bass machine.
1. Prepare a bassline pattern on the bass machine.
2. Connect the output of the bass machine to the mixer using a Mono jack 6.3 mm male cable.
3. Connect the Digitone audio outputs to the mixer using 2 x Mono or Stereo jack 6.3 mm male cables.
4. Use a DIN connector cable to connect the MIDI OUT of the Digitone to the SYNC IN of the bass
machine.
5. On the Digitone, press [GLOBAL SETTINGS], and then navigate to MIDI CONFIG > PORT CONFIG
and set OUT PORT CONFIG to DIN24.
6. Press [PLAY] on the Digitone.

16.2 DIGITONE TOGETHER WITH THE DIGITAKT

MAIN OUT TO MIXER
MIDI OUT TO DIN SYNC
MIDI OUT TO MIDI IN
OUTPUTS TO INPUTS
DIGITONE
16. SETUP EXAMPLES
MONO PHONE TO MIXER
DIGITAKT
