14. GLOBAL SETTINGS MENU
Make sure to use the USB only setting for the INPUT FROM or OUTPUT TO settings
on the MIDI PORT CONFIG menu when you send or receive large amounts of data for
higher transfer speeds.
OUTPUT CH selects whether the knobs sends data on the auto channel or the track channel.
PARAM OUTPUT selects what type of MIDI messages the DATA ENTRY knobs sends. For information
about which CC/NRPN parameters that are sent, please see "APPENDIX B: MIDI IMPLEMENTATION"
on page 79.
NRPN sends NRPN MIDI messages.
CC sends CC MIDI messages.
ENCODER DEST controls whether the DATA ENTRY and LEVEL/DATA knobs send MIDI data or not.
When set to INT, the knobs only affect the Digitone and send no MIDI data. When set to INT + EXT, the
knobs affect the Digitone and also sends MIDI data to external devices.
TRIG KEY DEST controls whether the [TRIG] keys sends MIDI data or not. When set to INT, the
[TRIG] keys only affect the Digitone and sends no MIDI data. When set to INT + EXT, the [TRIG] keys
affect the Digitone, and also send MIDI data to external devices. When set to EXT, the [TRIG] keys do
not affect the Digitone but send no MIDI data externally.
MUTE DEST controls whether activating/deactivating mutes send MIDI data or not. When set to INT,
mutes only affect the Digitone and no MIDI data is sent. When set to INT + EXT, mutes affect the Dig-
itone and also send MIDI data to external devices. When set to EXT, mutes send MIDI data externally,
but do not affect the Digitone.
RECEIVE NOTES sets whether or not it is possible to use an external MIDI keyboard or controller to
play the Digitone.
RECEIVE CC/NRPN sets whether or not it is possible to use an external MIDI device to control Digi-
tone parameters with CC/NRPN data.

14.3.3 CHANNELS

This menu handles the MIDI channel configuration.
TRACK 1–4 CHANNEL selects dedicated MIDI track channel that controls the synth tracks. It also
sets the MIDI channel for the MIDI messages the DATA ENTRY knobs on the chosen track send. An
OFF setting makes the track disregard any incoming MIDI messages.
MIDI 1–4 CHANNEL selects dedicated MIDI track channel that controls the MIDI tracks. It also sets
the MIDI channel for the MIDI messages the DATA ENTRY knobs on the chosen track send. An OFF
setting makes the track disregard any incoming MIDI messages.
FX CHANNEL selects dedicated MIDI track channel that controls the FX parameters. It also sets the
MIDI channel for the MIDI messages the DATA ENTRY knobs on the FX pages send. An OFF setting
makes the track disregard any incoming MIDI messages.
AUTO CHANNEL selects the MIDI channel that gives access to the currently active track. If an exter-
nal MIDI keyboard connected to Digitone sends MIDI data on this channel, the keyboard controls the
active track. This function is useful when you want to change quickly between the active synth tracks
to play different sounds. The Digitone also uses the AUTO channel to record to the MIDI tracks from
external MIDI controllers.
PROG CH IN CH selects the MIDI channel that listens for incoming program change messages. An
AUTO setting uses the AUTO channel. Enable Digitone to respond to program change messages in
the MIDI SYNC menu. For more information, please see "14.3.1 SYNC" on page 60.
PROG CH OUT CH selects the MIDI channel that sends program change messages when changing
patterns. The AUTO setting uses the AUTO channel. Enable Digitone to send program change mes-
sages in the SYNC menu. For more information, please see "14.3.1 SYNC" on page 60.
62
