16. SETUP EXAMPLES
Digitone works very well together with the Digitakt, and you can, for example, route the audio from the Digi-
takt through the Digitone and sync the tempo of the sequencers.
1. Use a standard MIDI cable to connect the Digitakt MIDI OUT jack with the Digitone's MIDI IN jack.
2. Use two TR or TRS cables to connect the OUTPUT L/R from the Digitakt to the INPUT L/R on the
Digitone.
3. On the Digitakt, press [GLOBAL SETTINGS], and then navigate to MIDI CONFIG > PORT CONFIG
and set OUT PORT FUNC to MIDI.
4. In the same menu set OUTPUT to MIDI.
5. Press [GLOBAL SETTINGS], and then navigate to MIDI CONFIG > SYNC and set CLOCK SEND to
ON.
6. On the Digitone, press [GLOBAL SETTINGS], and then navigate to MIDI CONFIG > PORT CONFIG
and set INPUT FROM to MIDI.
7. Press [GLOBAL SETTINGS], and then navigate to MIDI CONFIG > SYNC and set CLOCK RECEIVE
to ON.
8. Press [PLAY] on the Digitakt
9. On the Digitone, press [FUNC] + [LFO] to open the MASTER page.
10. Adjust the IN L/R to set the level of the incoming audio from the Digitakt.
11. Set LPAN to L64 and RPAN to R63.
12. Adjust the CHR, DEL and REV parameters to add the Digitone's send effects to the Digitakt's audio.

16.3 CONTROLLING A SYNTHESIZER USING THE MIDI TRACKS

MAIN OUT TO MIXER
Digitone has extensive capabilities to use its sequencer's MIDI tracks to control other MIDI-equipped
synthesizers.
1. Use a standard MIDI cable to connect the Digitone MIDI OUT jack with the synthesizer's MIDI IN jack.
2. On the Digitone, press [GLOBAL SETTINGS], and then navigate to MIDI CONFIG > PORT CONFIG
and set OUT PORT FUNC to MIDI.
3. In the same menu set OUTPUT TO to MIDI.
68
MIDI OUT TO MIDI IN
MAIN OUT TO MIXER
