Sime MURELLE REVOLUTION 25 User, Installation And Servicing Instructions page 50

– Press the
Menu
screen
– turn the encoder to select the "TECHNICAL" menu
GENERAL SETTINGS
INFORMATION
TECHNICAL
Esc
– press the click encoder to access the modifiable area. The
following screen is displayed:
Confirm operation?
Cancel
– Press the
Cancel
menu.
– Press the
Confirm
State hybrid operation
Zone heating
Ht-boiler adjust. param.
Hot water
Boiler parameters
ˆ
Esc
– Turn the encoder to select the required submenu
– Press the click encoder to confirm the selected submenu
and access the modifiable parameters area.
50
button to view the "Menu" selection
MENU
[...]
[...]
[...]
Back
CONFIRM REQUEST
Confirm
button to go back to the "TECHNICAL"
button to access the submenus.
TECHNICAL
[...]
[...]
[...]
[...]
[...]
Back
m
CAUTION
When the submenu "Boiler parameters" is selected,
the following screen appears when the
encoder is pressed:
Fig. 129
– Turn the
– Press the
select the next digit
– Continue in this way until the CODE (or password) "1 2 3 4 5"
has been completed
Fig. 130
– Press the
area
settings"
Fig. 131
– where "Parameter index" refers to the parameter table "
Parameter setting and display"
– Turn the
parameters and check the value.
ENTER ACCESS CODE
Code: 0 0 0 0 0
Cancel Confirm
encoder to modify the first digit from 0 to 1
click encoder to confirm the modification and
ENTER ACCESS CODE
Code: 1 2 3 4 5
Cancel Confirm
button to access the boiler "Parameter
Confirm
Boiler parameters
1--------49
Parameter Index: 1
Parameter Value: 0
Esc Back
encoder to scroll through the list of
click
Fig. 132
Fig. 133
Fig. 134
